Immediate priority ceiling protocol

/*
  ceil04
  task1 and task each 200 tick peiode and 60 tick tiem eating in mutex

  mutex by semaphore of ceiling mutex
  Set/Reset by #defein CEIL

  Using debug on PORTB(Uno et al) or PORTA(Mega's)
*/

#include <krnl.h>

#define STK 150

char stak1[STK], stak2[STK], stak3[STK];
struct k_t * pTask1, *pTask2, *pTask3, *sem1, *sem2, *sem3, *sem4;

#define CEIL

void task1()
{

  k_set_sem_timer(sem3, 200);
  while (1) {
    k_wait(sem3, 0);
#ifdef CEIL
    k_mut_ceil_enter(sem1, 0);
#else
    k_wait(sem1, 0);
#endif

    bugBitSet(4); // vipper bit 4 DIO 4
    k_eat_time(60);
    bugBitReset(4);

#ifdef CEIL
    k_mut_ceil_leave(sem1);
#else
    k_signal(sem1);
#endif
  }
}


void task2()
{
  k_set_sem_timer(sem2, 200);

  while (1) {
    k_wait(sem2, 0);

#ifdef CEIL
    k_mut_ceil_enter(sem1, 0);
#else
    k_wait(sem1, 0);
#endif

    bugBitSet(5);
    k_eat_time(60);
    bugBitReset(5);

#ifdef CEIL
    k_mut_ceil_leave(sem1);
#else
    k_signal(sem1);
#endif
  }
}

void task3()
{
  k_set_sem_timer(sem4, 60);
  while (1) {
    k_wait(sem4, 0);
    k_eat_time(20);
  }
}

void setup() {
  // for debugging - only on uno eq- If Mega etc use PORTA(which is pn 22,23,...)
  // see http://kom.aau.dk/~jdn/edu/doc/arduino/mega.png

  init_IO_for_debug(); // see code below

  Serial.begin(9600);

  k_init(3, 4, 0); // 2 task, 1 semaphores, 0 messaegQueues */

  pTask1 = k_crt_task(task1, 9, stak1, STK);
  pTask2 = k_crt_task(task2, 15 , stak2, STK);
  pTask3 = k_crt_task(task3, 13 , stak3, STK);

  sem1 = k_crt_sem(1, 10); // 1: start value, 10: max value (clipping)
  sem2 = k_crt_sem(0, 10); // 1: start value, 10: max value (clipping)
  sem3 = k_crt_sem(0, 10); // 1: start value, 10: max value (clipping)
  sem4 = k_crt_sem(0, 10); // 1: start value, 10: max value (clipping)

  k_mut_ceil_set(sem1, 8);

  k_start(1); /* start krnl timer speed 1 milliseconds*/

  Serial.println("If you see this then krnl didnt start :-( ");
}

void loop() {}

/***********************************************************************/


void init_IO_for_debug()
{
#if defined(__AVR_ATmega168__) || defined(__AVR_ATmega328P__) || defined(__AVR_ATmega328__)
  for (int i = 8; i < 8 + 6; i++)
    pinMode(i, OUTPUT);

#elif defined (__AVR_ATmega2560__) || defined (__AVR_ATmega1280__) || defined(__AVR_ATmega2561__)
  for (int i = 22; i < 22 + 6; i++)
    pinMode(i, OUTPUT);
#endif

}

/**********************************************************************/
/***** DEBUGGING PART - LED ON 8-12**********/
/************************ DEBUG CALLBACK BREAKOUT PART ****************/
// must be extern C ! its not mandatory to supply with these  functions - only if you need

volatile unsigned char reg = 0;

void bugBitSet(int bitNr)
{
  DI();
  reg = 1 << bitNr;

#if defined(__AVR_ATmega168__) || defined(__AVR_ATmega328P__) || defined(__AVR_ATmega328__)

  PORTB  = (1 << pRun->nr) | reg;  // arduino uno !! specific usage of PORTB

#elif defined (__AVR_ATmega2560__) || defined (__AVR_ATmega1280__) || defined(__AVR_ATmega2561__)

  PORTA  = (1 << pRun->nr) | reg; //  // arduino uno !! specific usage of PORTB

#endif
  EI();
}

void bugBitReset(int bitNr)
{
  char r;
  DI();
  r = ~(1 << bitNr);
  reg = 0;
#if defined(__AVR_ATmega168__) || defined(__AVR_ATmega328P__) || defined(__AVR_ATmega328__)

  PORTB  = (1 << pRun->nr) & r;  // arduino uno !! specific usage of PORTB

#elif defined (__AVR_ATmega2560__) || defined (__AVR_ATmega1280__) || defined(__AVR_ATmega2561__)

  PORTA  = (1 << pRun->nr) & r; //  // arduino uno !! specific usage of PORTB

#endif
  EI();
}



extern "C" {

  void k_sem_clip(unsigned char nr, int i) {}

  void k_sem_unclip(unsigned char nr) {}

  void k_send_Q_clip(unsigned char nr, int i) {}

  // task numbering is in creation order: dummy: 0,  first of yours 1, next 2,...
  void k_breakout() // called every task shift from dispatcher
  {

    // if we do have a uno,nano etc use PORTB directly
#if defined(__AVR_ATmega168__) || defined(__AVR_ATmega328P__) || defined(__AVR_ATmega328__)

    PORTB  = (1 << pRun->nr) | reg;  // arduino uno !! specific usage of PORTB

#elif defined (__AVR_ATmega2560__) || defined (__AVR_ATmega1280__) || defined(__AVR_ATmega2561__)

    PORTA  = (1 << pRun->nr) | reg; //  // arduino uno !! specific usage of PORTB

#endif

  }
  // get inspired at http://kom.aau.dk/~jdn/edu/doc/arduino/ards.html
}
